Portable 868 MHz Bluetooth Gateway, equipped with on button and 4 x configurable buttons for sending wireless commands; battery powered (9V), with integrated digital lux metre for configuration of the wireless systems, in combination with the free App for smartphones (App Store and Google Play).
Can be wall mounted for use as a wireless push‑button panel: see instructions given on technical data sheet.
868 MHz wireless controller for the management of a DALI or D1‑10V driver (possibility to connect through a DALI cable no. 4 driver, "broadcast" command), equipped with 500VA relay output and integrated wire antenna, housed inside a box made of plastic material 110x110x45mm, IP54 protection rating. 230Vac power supply.
Brightness and movement sensor for high environment (Hmax 16m), equipped with 868 MHz wireless controller for the management of a DALI or D1‑10V driver (possibility to connect via a DALI cable n.4 driver, "broadcast" command), 500VA relay output and integrated wire antenna, housed inside a box made of plastic material 110x110x45mm, IP54 protection rating. 230Vac power supply.
Brightness and movement sensor for high environment (Hmax 16m), equipped with 868 MHz wireless controller for the management of a DALI or D1‑10V driver (possibility to connect via a DALI cable n.4 driver, "broadcast" command or addressed), 500VA relay output, digital input, potential free contact and integrated wire antenna, housed inside a 110x110x45mm plastic case, IP54 protection rating. 230Vac power supply.
868 MHz wireless controller to manage a DALI or D1‑10V driver (it is possible to connect 2 “broadcast” command DALI drivers using a cable), compatible with Philips Xitanium SR and Osram DEXAL, dimensions 83x30x19 mm, IP20 protection rating.
DALI or 12 Vdc power supply.
IP66 polypropylene, RAL 7035 colour box, dimensions 110x110x66 mm, to house the RFxDRIVER wireless control module.
DALI‑SENSE‑BMS manages a group of DALI/DALI DT8 fixtures that are cabled in automatic and manual mode using integrated brightness and movement sensors.
DALI‑SENSE‑BMS works in an interconnected mode with all other components in the system and can therefore be used to create multi‑group applications and can be centralised via Ethernet with BMS and third‑party software.
SERVER to control cables DALI fixtures (max 64 drivers) and wireless 868 MHz.
Includes the web‑based xSERVER Setup app to configure the system.
Ethernet interface.
Powered DALI interface.
4 digital inputs, 4 digital outputs.
RS485 interface.
USB Input.
SMA connector for external antenna.
24 Vdc power astronomical clock.
DIN rail installation (L=105 mm).
Gateway, module for centralisation of 868 MHz wireless nodes on the TCP/IP network.
Ethernet interface.
Integrated antenna.
230 Vac power supply.
IP54.
App free to configure wireless 868 MHz ZETAQLAB devices, available for Apple (iOS) and Android Smartphones and Tablets.
DALI‑SENSE App allows you to configure the operating parameters and working methods of the wireless multisensory DALI‑SENSE and to manage the DALI fixtures connected manually.
The DALISENSE App is compatible with Smartphones and Tablets with a Bluetooth Low Energy interface with Android or iOS operating systems and can connect directly with the DALISENSE sensors using a Bluetooth LE interface.
Software for local (intranet) and remote (internet) systems management that makes it possible to configure, monitor and control all integrated systems and all fixtures connected through manual operations and by using automatic algorithms based on calendar events and conditional logic.
The software also allows to archive and export data relating to energy consumption and carry out automatic tests on Emergency devices and UPS, allowing to export the register of various activities, as prescribed by current regulations.
For more information contact the headquarters or regional offices.
